Custom designed for underfloor installations

Inverter Underfloor Ducted

Daikin’s Underfloor Ducted Systems are an ideal solution for homes in colder climates where heating is a focus. In these situations, units are typically installed underfloor to promote even warm air distribution throughout the home.

Features Controllers Technologies Tech Specs Brochures

Available in

Reverse Cycle
Capacities

Single Phase: 7.1kW, 12.5kW, 15.5kW
Three Phrase: 7.1kW, 12.5kW, 15.5kW
Refrigerant

R32

Engineered to deliver a compact and efficient design, our Inverter series is ideal for installation into the tight roof space of any modern home and now also features R22 retrofit capability for 5.0-15.5kW models.

Warranty info

Proudly
Australian Made

learn more

Through our commitment to expand local manufacturing capability, Daikin Australia are proud to announce that a range of products have successfully gained Australian Made certification.

Learn More

Key Features

It's the unique features of Daikin products that makes us the world leader.

Improved Energy Efficiency

Achieved through the use of a DC Fan motor, cross-pass heat exchanger and increased outdoor coil passes.
Compact Indoor Unit

Low profile height of ≤360mm to fit comfortably into the tight roof space of a modern home.
Space Saving Outdoor Unit

Models up to 19.5kW are encased in a space saving side discharge outdoor unit allowing for flexible placement.
Night Quiet Mode

Reduces the outdoor noise levels during sleeping hours and automatically resumes normal operations in the morning.
R22 Retrofit Capability

Provides a cost effective and convenient upgrade from an existing R22 ducted system whilst retaining the field piping (5.0-15.5kW Models).
Australian Made

Indoor units are specifically designed and manufactured to Australian standards to withstand the harsher summer climate.

Choose a winner

learn more

Daikin was recently awarded Australia’s Most Trusted Brand for Air Conditioners! We’re proud that thousands of Australians put their trust in our brand!

5 Year Warranty

learn more

Daikin's 5-year parts and labour warranty applies to split, multi split and ducted air conditioners purchased and installed in homes across Australia

INVERTER DUCTED Technology

1 2 3 4

INVERTER DUCTED Technology

1 Indoor Heat Exchanger

Our new indoor heat exchangers have been designed to deliver maximum capacity output in a compact casing size. Through the use of cutting edge technologies, our indoor heat exchangers utilise Ø5mm copper pipes to ensure heat is removed from your home efficiently.

2 Enhanced Reliability

Designed for the harsh Australian summer. The indoor unit fail safe logic regulates the fan speed on start-up when roof temperatures are at an extreme for enhanced reliability.

3 DC Fan Motor

Daikin indoor units are equipped with a high efficiency DC fan motor. By utilising high power permanent magnets instead of the induced magnetism of conventional AC motors, Daikin’s DC motor can deliver significantly higher motor efficiency.

4 Sirocco Fan

Daikin’s ducted units are fitted with light weight single injection moulded Sirocco Fans. These fans feature an aerodynamic fan blade design which reduces turbulence for a more efficient and quieter airflow delivery.

Ducted Systems

A Daikin ducted system provides discreet air conditioned comfort throughout your entire home. It can be installed in a new home or tailored to suit an existing one, and once installed, only the controller, the return air and discharge grilles are visible inside your home.

Download Brochure

Technical Specifications

Available Options:

System: Reverse Cycle
Capacities: Single Phase: 7.1kW, 12.5kW, 15.5kW, Three Phrase: 7.1kW, 12.5kW, 15.5kW
Indoor Type: Ducted
Power Supply: 1 Phase, 220-240V, 50Hz, 3 Phase, 380-415V, 50Hz
Refrigerant: R32

Show Full Tech Specs

Inverter Ducted Underfloor - Single Phase

Indoor Unit		FDYUAN71AV1	FDYUAN125AV1	FDYUAN160AV1
Outdoor Unit		RZA71C2V1	RZA125C2V1	RZA160C2V1
Rated Capacity	Cool (kW)	7.1	12.5	15.5
Rated Capacity	Heat (kW)	7.5	15	18
Capacity Range	Cool (kW)	1.8-8.0	4.0-14.0	7.3-16.3
Capacity Range	Heat (kW)	2.0-9.0	4.1-16.0	7.3-18.2
Power Input (Rated)	Cool (kW)	2.20	3.94	4.95
Power Input (Rated)	Heat (kW)	1.93	4.00	4.90
E.E.R/C.O.P	C/H	3.23/3.89	3.17/3.75	3.13/3.67
TCSPF (Residential)	Hot/Average/Cold	4.42/3.86/3.92	4.25/3.90/4.01	4.05/3.76/3.86
HSPF (Residential)	Hot/Average/Cold	4.17/3.85/3.41	4.31/3.31/2.77	3.87/3.53/3.12
Airflow Rate (Nominal/Max)	l/s	425/566	755/840	950/1120
Indoor Sound Level (H) @ 1.5m	dBA (C/H)	37.3/40.5	44.2/45.5	47.9/50.7
Piping Length	m	50
Indoor Fan Speeds		H/M/L
Dimensions (HxWxD)	Indoor (mm)	300x1210x900	360x1520x935
Dimensions (HxWxD)	Outdoor (mm)	595x845x300	990x940x320	1430x940x320
Weight	Indoor (kg)	40	55	56
Weight	Outdoor (kg)	45	78	99
Power Supply	V/Hz	1 Phase, 220-240V, 50Hz
Compressor Type		Hermetically Sealed Swing Type
Refrigerant		R32
Pipe Sizes	Liquid (mm)	9.5 (Flared)
	Gas (mm)	15.9 (Flared)
	Drain (mm)	ID 25 / OD 32
Supply Air Opening	mm (HxW, Flange)	185x852	245x1152
Return Air Opening	mm	1x400 (Oval)	2x400 (Oval)
Outdoor Operating Range	Cool (°CDB)	-5 to 46
Outdoor Operating Range	Heat (°CWB)	-15 to 16
EPA Sound Power Level	dBA	68	72	75
Outdoor Sound Level (H) @ 1m	Pressure dBA (C/H)	48/51	53/54	56/58

Inverter Ducted Underfloor - Three Phase

Indoor Unit		FDYUAN71AV1	FDYUAN125AV1	FDYUAN160AV1
Outdoor Unit		RZA71C2Y1	RZA125C2Y1	RZA160C2Y1
Rated Capacity	Cool (kW)	7.1	12.5	15.5
Rated Capacity	Heat (kW)	7.5	15	18
Capacity Range	Cool (kW)	3.2-8.0	4.0-14.0	7.3-16.3
Capacity Range	Heat (kW)	3.5-9.0	4.1-16.0	7.3-18.2
Power Input (Rated)	Cool (kW)	2.20	3.94	4.95
Power Input (Rated)	Heat (kW)	1.93	4.00	4.90
E.E.R/C.O.P	C/H	3.23/3.89	3.17/3.75	3.13/3.67
TCSPF (Residential)	Hot/Average/Cold	4.44/3.91/3.98	4.25/3.90/4.01	4.05/3.76/3.86
HSPF (Residential)	Hot/Average/Cold	4.17/3.90/3.55	4.31/3.31/2.77	3.87/3.53/3.12
Airflow Rate (Nominal/Max)	l/s	425/566	755/840	950/1120
Indoor Sound Level (H) @ 1.5m	dBA (C/H)	37.3/40.5	44.2/45.5	47.9/50.7
Piping Length	m	50
Indoor Fan Speeds		H/M/L
Dimensions (HxWxD)	Indoor (mm)	300x1210x900	360x1520x935
Dimensions (HxWxD)	Outdoor (mm)	595x845x300	990x940x320	1430x940x320
Weight	Indoor (kg)	40	55	56
Weight	Outdoor (kg)	45	78	99
Power Supply	V/Hz	3 Phase, 380-415V, 50Hz
Compressor Type		Hermetically Sealed Swing Type
Refrigerant		R32
Pipe Sizes	Liquid (mm)	9.5 (Flared)
	Gas (mm)	15.9 (Flared)
	Drain (mm)	ID 25 / OD 32
Supply Air Opening	mm (HxW, Flange)	185x852	245x1152
Return Air Opening	mm	1x400 (Oval)	2x400 (Oval)
Outdoor Operating Range	Cool (°CDB)	-5 to 46
Outdoor Operating Range	Heat (°CWB)	-15 to 16
EPA Sound Power Level	dBA	72	73	75
Outdoor Sound Level (H) @ 1m	Pressure dBA (C/H)	53/56	54/56	56/58
