DAIKIN AIRHUB
Ultimate Air Control For Your Home
Daikin's new AirHub Touch Zone Controller with its contemporary design, intuitive controls and innovative features will give you the flexibility to deliver precise temperature control and ultimate comfort to where it is needed in your home.
Key Features
It's the unique features of Daikin products that makes us the world leader.
-
Touch Operation
7” colour resistive touch screen interface housed in a contemporary casing design with a matte white finish.
-
Two Versions
Both On/Off or Linear Control options available in either a 4 or 8 zone design. For details on these control methods, see brochure.
-
Optional Wireless Sensors
Wireless remote temperature sensors are available, ideal for homes with internal brick walls.
-
On/Off Timer
Program on and off times within the day to suit your needs.
-
Weekly Schedule Timer
Program on and off times, including when to open/close zones and the temperature sensor to use for On/Off Control option.
-
Eco Settings
Setpoint Range Limit, Setpoint Auto Reset and Auto Off Timer enables you to easily reduce your system's energy consumption.
Sensor Options
Wired Sensor
Wireless Sensor
Technical Specifications
| AIRHUB ITEMS | |
|---|---|
| BRCMTZCB9 | Main Zone Controller |
| BRCSTZCB9 | Sub Zone Controller |
| BRC24TZ4B9 | 4 Zone, On/Off Zone Controller Box (24V) |
| BRC24TZ8B9 | 8 Zone, On/Off Zone Controller Box (24V) |
| BRC24TLZ4B9 | 4 Zone, Linear Zone Controller Box (24V) |
| BRC24TLZ8B9 | 8 Zone, Linear Zone Controller Box (24V) |
| BRCS01A-1 | Wired Temperature Sensor |
| BRYW1B-1 | Wireless Temperature Sensor |
| BRYW1B-2 | Wireless Sensor Receiver |
| CONTROLLER SPECIFICATION | |
|---|---|
| HxWxD (mm) | 134x232x64 (11mm Flush) |
| Screen (Diagonal) | 7.00” |
| SENSOR SPECIFICATION | |
|---|---|
| Wired - HxWxD | 50x60x20 |
| Wireless - DIAxD | Ø67x15 |
Need a second controller?
Daikin Airbase is a great option!
Learn more
AIRHUB COMES IN TWO VERSIONS
1. ON/OFF ZONE CONTROL*
Traditional On/Off Control solution only allow zones to be turned on or off without the ability to set temperatures. Daikin's solution takes this one step further with Airside Control.
2. LINEAR ZONE CONTROL**
Our Linear Control solution enables you not only to turn on or off but also set the zone temperature to within ±2°C from the main set point. Daikin's Linear Control also features our proprietary OptiZone Control.
*Only compatible with all Premium Inverter & Inverter Ducted models, however Airside Control feature is not available on R410A (FDYQN) Inverter Ducted series.
**Only compatible with R32 (FDYA) Premium Inverter Ducted 71-160 Class & R32 (FDYAN) Inverter Ducted 50-160 Class.
WHAT IS AIRSIDE CONTROL?
As zones are turned off, the indoor unit fan reduces speed between 60-100% of the nominal airflow rate to meet the airflow requirement of the remaining open zones for quieter operation and greater energy savings.
WHAT IS OPTIZONE CONTROL?
OptiZone Control will automatically regulate the individual zone dampers to deliver precise airflow to meet the temperature settings and heat load of each zone. As the zone dampers adjust, the indoor unit fan speed will intelligently regulate between 30-100% of the nominal airflow rate to deliver the required airflow to maintain the comfort levels of each zone.
On days when the heat load is mild or low, significant energy savings can be achieved through OptiZone Control, truly optimising the system for ultimate comfort.
Daikin AirHub
